Specifications:

• AV Interface: HDMI
• Interface Standard: HDMI 1.4
• Supported Bandwidth: 10.2Gbps
• Maximum Resolution: 3840 x 2160 @ 30Hz
• Audio EDID: LPCM 2-channel | 16/20/24 bit depths at 32/44/48/88/96/176/192 kHz
• HDCP Support: 1.4
• Input: HDMI Type-A Male
• Output: HDMI Type-A Female
• Power: Via HDMI Source Interface
• Housing Material: ABS
• Dimensions: 24 x 43 x 12.3mm
• Weight: 0.008kg
• Warranty: 2 Years
• Certificated: CE | FCC | RoHS | REACH

Features:

• Continuously emulates HDMI EDID information
• Supports resolutions up to 3840×2160@30Hz including HDCP pass-through
• For use with 32120 for cloning
• Powered via HDMI Source Interface
• 2 Year warranty

Video EDID Resolutions & Framerate:

• 640 x 480p 60/72/75Hz
• 720 x 400p 60Hz/70Hz
• 720 x 480i 60Hz
• 720 x 576p 50Hz
• 720 x 576i 50Hz
• 800 x 600p 56/60/72/75Hz
• 832 x 624p 75Hz
• 1024 x 768p 60/70/75Hz
• 1280 x 800p 60Hz
• 1280 x 720p 50/60Hz
• 1152 x 864p 75Hz
• 1152 x 870p 75Hz
• 1280 x 1024p 60/75Hz
• 1280 x 960p 60Hz
• 1440 x 900p 60Hz
• 1600 x 1200p 60Hz
• 1680 x 1050p 60Hz
• 1920 x 1080i/p 50/60Hz
• 1920 x 1200p 60Hz
• 2560 x 1440p 60Hz
• 3840 x 2160p 24/30Hz
